Full Hydraulic 350m Pneumatic Water Well Drilling Rig
Introduction of ST350 pneumatic drilling rig
Water and air drilling rig is an efficient and multifunctional drilling equipment. It is mainly suitable for drilling water wells,
agricultural irrigation wells, geothermal air conditioning holes and other wells, especially suitable for water intake projects in mountainous areas and rock formations. . The efficiency is ten times higher than that of traditional rotary drilling rigs, and the economic benefits created for users are extremely considerable. In particular, it solves the difficulty in drilling the soil layer with air DTH hammer, and the construction problem of the rotary drilling rig in the hard rock layer, gravel and pebble layer. It can work efficiently under various geological structures and realize the perfect combination of water drilling and air drilling.
Parameters of 350 water well drilling rig
| Technical Parameters of ST300 water well drilling rig | |
| type | ST350 |
| The weight | 9.8T |
| Dimension | 6m×2m×2.5m |
| The hole diameter | 105-305mm |
| Drilling depth | 350m |
| One-time advance length | 6m |
| Walking speed | 2.5KM/H |
| Climbing angles | 30 |
| Power | 92KW |
| Using air pressure | 1.7-3.3MPA |
| Air consumption | 17-35 |
| Drill pipe length | 1.5m 2.0m 3.0m 6.0m |
| Drill pipe diameter | 89mm,102mm, |
| Rig lifting force | 20T |
| Swing speed | 55-115rpm |
| Swing torque | 6200-85000N.m |
Characteristics of pneumatic drilling rig
1. The drilling rig hydraulic transmission of the rig effectively utilizes the power. This makes the overall power loss small and the drilling cost low.
